Designed for warehouse and industrial use, the Paxum X0ms Stretch Wrap Machine is designed to increase the speed, safety and efficiency of the pallet wrapping process.
Quick-start, hands-free pallet wrapping
Paxum X0ms’ ‘one-button start’ function saves time and allows users to step away and attend to other matters while wrapping is underway, increasing onsite productivity and efficiency.
The reduced need for manual operation, therefore, improves operator safety and reduces training time.
Centralised control and coordination
Paxum X0ms’ Printed Circuit Board control system serves as the centre point of the machine’s operations; controlling, coordinating and aligning each of the machine’s functions including:
Better wrapping quality with improved stability
The all-in-one design of Paxum X0ms’ aluminium mast is less likely to wobble or vibrate during use, providing greater stability resulting in better quality, faster, and more efficient wrapping.
Aluminium requires less maintenance and has a longer lifespan than many other metals, withstanding harsh conditions present at any work site, including extreme temperatures and excess moisture levels.
Inbuilt photoelectric sensors, for finely focused accuracy
Paxum X0ms’ photo-electric sensors accurately detect a pallet’s height, ensuring that the stretch film is uniformly applied to the entire pallet, eliminating the need for guesswork and manual adjustments, which can lead to errors and inconsistencies.
These also help to prevent workplace accidents by detecting any obstacles or obstructions on the pallet, such as loose or protruding items, ensuring that the wrapping process is carried out safely.
Automated tension control, for smooth consistency and wrapping results
Paxum X0ms’ mechanical tension control optimises stretching ensuring that film is securely wrapped around the pallet with a consistent tension, regardless of the shape and size of the load being wrapped.
This helps to reduce the risk of damage during transit or storage and minimises the quantity of film needed for every wrap, reducing waste and providing long-term savings to your business.
Enhance your operations with Paxum X0ms’ reliable memory functions
Paxum X0ms features an ability to store and recall six specific wrapping patterns and settings, with its inbuilt microprocessors and digital memory.
This function reduces manual errors, offering reliability and continuity, and allowing operators to easily recall specific configurations for different pallet shapes, sizes and loads to meet varying requirements.
Main Features
| Production Rate: | 25-30 loads/hour |
| Turntable Speed: | 3-10RPM |
| Turntable Diameter : | 1500mm |
| Turntable Height: | 81mm |
| Max. Load Weight: | 1500kgs |
| Std. Wrapping Height: | 2000mm |
| Pre-stretch Rate: | Mechanical stretch |
| Up & Down Speed: | 1.5-5m/min |
| Noise Decibel: | ≤75dB(A) |
| Working Environment: | Humidity: ≤90% / Temperature: -10 - 45°C |
| Voltage: | 240V |
| Machine weight: | 530kg |
| Machine size: | L2444*W1500*H2463(mm) |
| Film Spec: | 500mm wide, Core Diameter 76mm |
| Technical Data: | Operation Manual |
| Warranty: | 3 Years |
Introducing the new Paxum X0ms Pallet Stretch Wrapping Machine.
The Paxum-X0ms is an entry level machine designed for warehouse and industrial applications.
The Paxum X0ms Features.
The Paxum X0ms is a low cost, effective and reliable solution for many pallet wrapping applications.
Contact us today to learn more about how the Paxum X0ms can benefit your business.
Same Day Despatch
How is the load initially placed for wrapping?
The pallet with the goods to be wrapped is placed onto the turntable or conveyor system of the wrapping machine. The machine should have adjustable guides or fences to ensure the pallet is properly aligned.
The operator attaches the end of a stretch film roll to the pallet, typically by manually starting the film around one of the bottom corners or using an automatic film attachment mechanism.
The operator sets the wrapping parameters on the machine’s control panel. These parameters may include the number of wraps, wrapping tension, film overlap, and rotational speed of the turntable (if applicable).
Once the parameters are set, the machine initiates the wrapping process. The turntable rotates, or the film carriage moves up and down, while the film is automatically unwound and stretched as it is applied to the pallet.
After completing the desired number of wraps, the machine cuts the film and secures it to the pallet. This can be done using a heat-sealing mechanism or by pressing the film against itself to create a tight bond.
Once the wrapping is finished, the operator removes the wrapped pallet from the machine, making space for the next one.
