The mast height of the S300 pallet wrapping machine is 3200mm, and the maximum packing height it can accommodate is 2400mm. If your pallet exceeds 2400mm in height, you will need to choose a mast height of 3900mm, allowing for a maximum packing height of 3200mm.
What is the estimated delivery duration for my order?
We provide same-day dispatch for available items if ordered before 2:30 p.m.*
Metropolitan Area
| Sydney | 1-2 Business Days |
| Melbourne | 1-2 Business Days |
| Adelaide | 1-2 Business Days |
| Brisbane | 1-3 Business Days |
Perth
| Perth | 5-7 Business Days |
Regional Area
| Victoria | 2-3 Business Days |
| Queensland | 2-3 Business Days |
| South Australia | 2-3 Business Days |
| New South Wales | 2-3 Business Days |
| ACT | 2-3 Business Days |
Northern Territory
| Northern Territory | 5-7 Business Days |
Tasmania & Western Australia*
| Tasmania & Western Australia* | 5-7 Business Days |
*Same-day dispatch is not available for products sourced upon request, including machinery and equipment.
It's important to note that there will be a lead time for these items, depending on their availability.
*Attention to our valued customers in Western Australia: To ensure consistent availability of your requested items, please note a potential lead time of 5-7 days for orders shipped from our Victorian warehouses.
The Paxum® Inline Fully Automatic Pallet Wrapping Machine – S300 is an efficient, automatic, and low power consuming machine that is perfect for any production line. With its fully customizable wrapping cycles, it can efficiently handle the wrapping of products, ensuring a secure and tight grip. This machine is equipped with an automatic reading testing feature using a photoelectric sensor, which ensures the machine moves smoothly through the wrapping process.
The stainless-steel conveyor of the Paxum® S300 is durable and can withstand high usage, making it a long-term investment for any business. The conveyor is equipped with an 89mm stainless steel roller, which ensures seamless transition of pallets from input/output conveyor to the wrapper. This feature provides superior pallet wrapping for maximum load containment.
The Paxum® S300 Fully Automatic Inline Pallet Stretch Wrapper has a maximum load capacity of 3000KG that makes it capable of handling heavy pallets. This machine is equipped with a pallet grip system that transforms the Machine Stretch Film into a shrink rope, thereby gripping the pallet and products securely during wrapping. It eliminates any concerns of product fall during transportation and negates the need for horizontal strapping machines.
The Paxum® S300 is programmed with a frequency converter option that enables it to be programmable, with soft start and stop features for pallet wrapping. This machine is equipped with a SIEMENS PLC Control System, which ensures long-term reliability and durability. The SIEMENS Control System offers superior quality, reducing the need for frequent maintenance and repair.
The Slewing Bearing Turntable is a unique feature of the Paxum® S300 Fully Automatic Inline Pallet Stretch Wrapper. It offers a maximum load weight of 3000KG, enabling a quieter operation and reduced vibration compared to chain drive turntables. With its remote-control operation feature, the Paxum® S300 makes the pallet wrapping process completely seamless. You can place the pallet on the turntable, press the remote-control button, and watch as the machine automatically stretch wraps the pallet. There is no need to leave the forklift or operate the machine manually.
In conclusion, the Paxum® S300 Inline Fully Automatic Pallet Wrapping Machine is an excellent investment for any business with its durable conveyor, SIEMENS PLC Control System, pallet grip system, Slewing Bearing Turntable, and remote-control operation feature. Its 300% pre-stretch ratio for optimal wrapping ensures maximum load containment, increasing the security in product transportation. It is a perfect fit for any production line, delivering efficient, automatic, and labour-saving operations while maintaining low power consumption.
Gateway Packaging also offers a variety of pallet wrapping machines and other options for your consideration.
For more information, please contact our friendly sales team to learn how our pallet wrapping machines can streamline your packaging process today!
Pallet Grip system
The pallet grip system transforms the Machine Stretch Film into a shrink rope, securely gripping the pallet and products during wrapping. This eliminates concerns of product fall during transportation and the need for horizontal strapping machines.
Slewing Bearing Turntable
The Paxum S300 Fully Automatic Inline Pallet Stretch Wrapper is standard with a slewing bearing turntable, offering a maximum load weight of 3000KG. Enabling a quieter operation and reduced vibration compared to chain drive turntables.
SIEMENS Control System
The Paxum S300 Fully Automatic Inline Stretch Wrapper is fitted with Superior Quality SIEMENS PLC Control System for long-term reliability.
Durable Conveyor
Equipped with an 89mm stainless steel roller. The chain drive on the joint conveyor ensures a seamless transition of pallets from the input/output conveyor to the wrapper, providing a superior pallet wrap for maximum load containment.
Remote Control Operation
Simply place the pallet on the turntable, press the remote-control button, and watch as the machine automatically stretch wraps the pallet. No need to leave the forklift or operate the machine manually.
| Model | S300 | Spare Parts | Brand |
|---|---|---|---|
| Maximum wrapping speed : | 30-40 loads/hour | Inverter | X-Line |
| Load Size Diagonal : | 1753mm | Position sensor | SICK(Germany) |
| Maximum Wrapping Height : | 2400mm | PLC | SIEMENS(Hongkong |
| Turntable Speed: | 0-15RPM(Adjustable) | Travel Switch | OMRON(Japan) |
| Turntable Size : | 2000mm | Motor | GPG |
| Turntable Drive : | 1.5PH | Relay | OMRON(Japan) |
| Cut & Clamp Fillm : | Automatic (Heat type) | Touch screen | SIEMENS 7inch |
| Max load weight : | 3000KG | Switch | Schneider |
| Standard Film Width : | 500mm | ||
| Constant Film Delivery Force : | Standard | ||
| Standard Pre-Stretch : | 300% pre-stretch | ||
| Roller Materials: | Stainless Steel 201 diameter :89mm | ||
| Film Capacity : | 250mm Diameter | ||
| Film Delivery System : | Power Roller -Stretch Plus | ||
| Film Rope System : | Standard | ||
| Weighing Scale : | Optional | ||
| Machine Weight : | 980KG | ||
| Machine Size : | L:2000mm W:1800mm H:3700mm | ||
| Turntable technology : | Slewing Ring | ||
| Voltage : | 380V/220V/50HZ 1phase | ||
| Warranty: | 3 Years |
Paxum® Inline Fully Automatic Pallet Wrapping Machine - S300
CODE: 62208Fully automatic wrapping solution built for high-volume production lines.
Introducing the S300 Paxum® Fully Automatic Pallet Stretch Wrap Machine, the ideal solution to streamline your automatic production line. With its Motor Drive Conveyor, this state-of-the-art machine ensures smooth packaging operations, saving you time and effort. Partnered with a high-quality Paxum® Machine Stretch Film for maximum load containment and stability during transport and storage.
Features:
Fully Customizable Wrapping cycles for production lines.
- Automatic reading testing with photoelectric sensor.
- Stainless-steel conveyor for durability.
- 300% pre-stretch ratio for optimal wrapping.
- Programmable control with frequency converter option.
- SIEMENS PLC controls
- Soft start and stop for pallet wrapping machine.
- Perfect for production lines.
- Efficient, automatic, low power consumption, labour-saving.
- Maximum load capacity: 3000KG.
- Warranty: 3 years
Optional Extras:
- Photocell Sensor for Black Stretch Wrap
Transform your production line with our Paxum® S300 Fully Automatic Pallet Wrapping Machine.
Please check the Specifications & Downloads below for brochures, SOPs & user guide manuals.
Calculate my ROI
Contact us today to explore how this innovative solution can elevate your operations and achieve seamless packaging.
Same Day Despatch
Hours
Minutes
Seconds
left
Same Day Despatch is guaranteed for all orders on stocked lines placed before 2pm AEST on business days.
Related Products
Frequently Asked Questions
-
What is the mast height of the S300 Model Inline Fully Automatic Pallet Wrapping Machine?
-
How do I choose a control system for the S300 pallet wrapping machine?
All S300 pallet wrapping machines come equipped with Siemens control systems. These top-quality control systems ensure a longer machine lifespan and consistent performance.
-
What is the standard turntable size for the S300 pallet wrapping machine?
The standard turntable size for the S300 model is 2000mm in diameter, providing ample space for pallet wrapping.
-
What is the turntable height of the S300 pallet wrapping machine, and is it adjustable?
The turntable height for the S300 model is 550mm, and it is adjustable to accommodate various pallet sizes and wrapping needs.
-
What is the maximum weight that the S300 pallet stretch wrapper can handle?
Our standard S300 pallet stretch wrapper can safely handle a maximum load weight of 3000 kilograms (3000KG).
